Harrington TNER Theatrical Chain Hoists

Harrington TNER Theatrical Chain Hoists – Great for all Theatrical and Entertainment Markets

TNER Series theatrical chain hoists were designed using the latest technology for handling stage and theatrical equipment. These high quality, low-headroom, full-featured hoists provide reliable performance for use in theaters, concert halls, arenas, stadiums and studios.

Theatrical Chain Hoists

Looking for Auditorium, Theater & Performing Art Center Inspections and Repairs, Click Here

Harrington TNER Theatrical Hoist

*** CLICK HERE for video of the amazing Harrington TNER ***

FEATURES

Standards
Hoist exceeds stringent world
standards; complies with
German regulation BGV-D8.
Standard configuration meets
CE Declaration.
Pull-Rotor Motor Brake
World’s most reliable theatrical
hoist brake. Simple design.
No brake coil to fail or brake
disc to replace. 5 year hoist
brake warranty.
Unique Chain Guide
Provides quiet and smooth
guiding of chain into hoist and
chain container. Durable, heavy
cast iron construction.
Sleek Rounded Body
Rugged aluminum housing;
no sharp edges and flexible
soft-grip handles.

Plug and Play Voltage Changer
Quickly change between
208/230V and 460V. Saves
valuable time during setup
and integration.
Low Profile Upper/Lower Limit
Switches
No adjustment required.
Protects hoist and provides
maximum travel.
Size and Speed
Designed to fit standard road
cases. ½ and 1 Ton—16 fpm;
2 Ton—8 fpm.
Grease-Packed Gearbox
For demanding theatrical
applications. Maintenance free.
No oil changes required.
Experiencing diarrhea after having cheap viagra from pfizer a gallbladder removed is not a new thing. Precautions: It shouldn’t be consumed along with alcohol as well as oily or fatty dinners. cheap viagra price The diagnostic tests that are involved in http://deeprootsmag.org/2019/02/01/the-deep-roots-elite-half-hundred-of-2018-pt-2/ cialis price this condition may harm your health badly. It deeprootsmag.org purchase viagra online might be explained in a way that there are only certain medications that can be described via an online Doctor, such as those that provide treatment for asthma, shingles, herpes, erectile dysfunction and thyroid conditions.

Nickel-Plated Load Chain
Meets DIN and EN 818-7
standards. Optional black
chain available.
Friction Clutch
Carbon friction material provides
consistent performance over a
wide temperature range.
Chain Container
Reversible black canvas
chain container needed to
meet BGV-D8 regulations.
Also designed with two
secure attachment points.
Optional Pendant
Control (Pickle)
Red button emergency stop.
Nema 4X, UL/cUL (CSA) listed.

STANDARD HOIST SPECIFICATIONS

Capacity Range
1/2 Ton – 2 Ton
Reconnectible Voltage
208-230/460-3-60
Control Voltage
110V
Duty Cycle*
30 Minutes
Classification*
ASME H3
JS/ISO M3
FEM 1Bm
Ratings
Hoist — IP55
Optional Pendant — NEMA 4X,
UL/cUL (CSA) listed

Chain Container
Standard
Canvas
Standard Lift
60’ (other lengths available)
Standard Pendant and
Power Supply Cord
2.5’ (longer lengths available)
Optional**
Pendant (Pickle)
Pendant Cord
Power Supply Cord
Hubbell, 7-Pin or 14-Pin Connectors
Road Case
Black Load Chain
Bullard® and Shur-Loc® Hooks
